PROJECT CASE
Guangda Electric Is A Professional Organization Dedicated To Solving Power Quality Problems Of Users
Yingde City Fuda Fuda Casting Processing Factory
User: Yingde City Fuda Fuda Casting Processing Factory Name: Outdoor high voltage automatic reactive power compensation and harmonic elimination device Model: MSCGD-5400/35 Load: medium frequency furnace and rolling mill 1. Power factor: The power factor is increased from 0.82 to 0.92, saving about 4.5% of electricity costs; 2. Harmonic elimination effect: the operation is stable, there is no hidden danger of resonance; 3. Applicable occasions: maintenance-free outdoor compensation, saving infrastructure investment; 4. Features of the device: It is suitable for relatively stable load; the compact structure occupies a small space; it can be unattended. 5. Supporting components: LCD display for status display and human-computer interaction, display is intuitive and easy to operate; and complete protection measures for various possible faults such as overvoltage and overcurrent.
2023-01-12
Shenzhen Guangshuo Environmental Protection Energy Co., Ltd.
User: Shenzhen Guangshuo Environmental Protection Co., Ltd. Name: Zero sequence filter Model: ZSFGD-150/0.4 Load: fluorescent and energy-saving lamps, UPS power supplies, and office equipment such as computers, printers, and photocopiers Before filtering: 1. High cable temperature, fire hazard: 75 ° C 2. Zero line current is large: 73A 3. Neutral current: More than 90% is the 3rd harmonic. After filtering: 1. The temperature of the neutral cable is reduced: from 75 ° C to 42 ° C; 2. Zero line current reduction: from 73A to 12A; 3. The energy saving effect is obvious: reduce the loss by 6kW.
2023-01-12
Guangzhou Diesel Engine Factory
User: Guangzhou Diesel Engine Factory Name: Low-voltage dynamic reactive power compensation and harmonic elimination device Model: TSCGD-800/0.4 Load: generator, mains dual-supply intermediate frequency furnace 1. Power factor: The control device can automatically switch between the generator and the mains, so that the power factor of the checkpoint is not less than 0.96; 2. Harmonic elimination effect: the 5th harmonic current drop is 14%, and the 7th harmonic current drop is 8.7%; 3. Temperature noise: The temperature of the user's generator is significantly reduced, the abnormal noise disappears, and the smelting cycle is significantly shortened. 4. Supporting components: using touch screen for status display and human-computer interaction, the display is intuitive and easy to operate; the management device is equipped with perfect sound and light protection measures for various possible faults.
2023-01-12
Fogang County Xinxin Hardware Foundry
User: Fogang County Xinxin Hardware Foundry Name: Low-voltage automatic reactive power compensation and harmonic control device Model: MSFGD-1200/0.66 Load: 3 sets of 1.5 tons of intermediate frequency furnace, 2 with 1 1. Power factor: The power factor is increased from 0.88 to over 0.95, saving electricity costs by about 2%, and the smelting cycle is significantly shortened; 2. Filtering effect: 5th, 7th, and 11th harmonic currents are reduced to 1.7%, 1.5%, and 1.2%, respectively; 3. Temperature noise: The temperature and noise of the transformer are significantly reduced, the load capacity of the transformer is enhanced, and the service life of the transformer is prolonged; 4. Supporting components: The management device adopts the LCD screen for status display and human-computer interaction, and completes the protection measures for various possible faults, and installs a rapid discharge device.
2023-01-12
Zhongtian Chuangzhan Ball Iron Co., Ltd.
User: Zhongtian Chuangzhan Ball Iron Co., Ltd. Name: Low-voltage automatic reactive power compensation and harmonic elimination device Model: MSCGD-2920/0.75 Load: 1 5000kW intermediate frequency furnace 1. Power factor: The power factor is increased from 0.77 to over 0.92, the monthly electricity cost is about 100,000 yuan, and the energy consumption per ton is reduced by 8.4%. 2. Filtering effect: the 5th harmonic current drop is 13% of the fundamental current, and the 7th harmonic current drop is 7.6% of the fundamental current; 3. Temperature noise: The temperature and noise of the transformer are significantly reduced, so that the transformer capacity is fully utilized; 4. Supporting components: LCD display for status display and human-computer interaction and complete protection measures for various possible faults.
2023-01-12
Shenzhen Shajing Changliupo Water Plant
User: Shenzhen Shajing Changliupo Water Plant Name: High-voltage automatic reactive power compensation and harmonic control device Model: MSFGD-270/10 Load: several pumps with variable frequency energy saving 1. Power factor: The power factor is increased from 0.86 to 0.93, saving about 2% of electricity costs; 2. Filtering effect: no fault occurs after installation, the harmonic current is significantly reduced, and the 5th harmonic is reduced to 2.5% of the fundamental current; 3. Temperature noise: the pump runs smoothly, no abnormal noise; the temperature and noise of the treatment device are stable; 4. Supporting components: LCD display for status display and human-computer interaction, display is intuitive and easy to operate; and complete protection measures for various possible faults such as overvoltage and overcurrent.
2023-01-12
